Specification




CAPACITY

AMAN

890

AMAN

1020

AMAN

1140

AMAN

1270

AMAN

1400

AMAN

1525

AMAN

1650

Table

Inche MM

Inche MM

Inche MM

Inche MM

Inche MM

Inche MM

Inche MM

Working Surface 8 x35 200 x890 9 x40 230 x1020 10 x45 255 x1140 11 x50 280 x1270 12 x55 305 x1400 13 x60 330 x1525 14 x65 360 x1650
Sewivel 45...... 45...... 45...... 45...... 45...... 45...... 45......
T.Slot Nos./Size 3-1/23-12 3-1/23-12 3-5/83-16 3-5/83-16 3-5/83-16 3-5/83-16 3-5/83-16
Distance between T.Slot 3-1/23-12 3-1/23-12 3-5/83-16 3-5/83-16 3-5/83-16 3-5/83-16 3-5/83-16
Spindle
No.Of Spindle Speeds 6...... 6...... 9...... 9...... 9...... 12...... 12......
Range of Spindle Speeds 50to 750 50to 750 40to 750 40to 750 40to 750 40t0 1100 40to 1100
Spindle Taper ISO- 40 ISO- 40 ISO- 40 ISO- 40 ISO- 40 ISO- 40 ISO- 40
Arbour Diameter 1 25.4 1 25.4 1 25.4 1 25.4 1 25.4 1 25.4 1 25.4
Feeds
Longitudinal (Manual/Auto) 18460 21 535 24610 27710 32840 38965 431090
Cross (in all geared only) 4.5115 6128 7152 9204 12280 14355 431090
Vartical (in all geared only) 10280 12305 14330 17430 20510 25636 29736
No of Auto Feeds 2...... 6...... 6...... 9...... 9...... 3...... ............
Feeds Range P/M Longi. .1mm to.3mm/Rec 10mm to 120mm 10mm to 120mm 10mm to 120mm 10mm to 120mm 10mm to 120mm ............
No. Of Auto feeds in all Geared ............ ............ ............ ............ 6...... 6...... 6......
Longitudinal Feeds / Min ............ ............ ............ ............ 1/2x612x152 1/2x612x152 1/2x612x152
Cross Feeds / Min. ............ ............ ............ ............ 1/2x612x152 1/2x612x152 1/2x612x152
Vertical Feeds / Min ............ ............ ............ ............ 1/16x1.5 1.5x38 1/16x1.5 1.5x38 1/16x1.5 1.5x38
Rapid (in all geared only)
No.Of Rapid Feeds ............ ............ ............ ............ 1...... 1...... 1......
Longitudinal Rapid/Min ............ ............ ............ ............ 35890 35890 35890
Cross Rapid/Min ............ ............ ............ ............ 35890 35890 35890
Vertical Rapid / Min ............ ............ ............ ............ 7178 7178 7178
Electrical
Main Motor 1 HP -1440 RPM 1 HP -1440 RPM 1 HP -1440 RPM 2 HP -1440 RPM 3 HP -1440 RPM 3 HP -1440 RPM 5 HP -1440 RPM
Feed Motor   1 HP -1440 RPM 1 HP -1440 RPM 2 HP -1440 RPM 2 HP -1440 RPM 1 HP -1440 RPM ............
Feed Motor (in all geared only) ............ ............ ............ 2 HP -960 RPM 2 HP -960 RPM 2 HP -960 RPM 3 HP -960 RPM
Coolant Pump 0.1 HP 0.1 HP 0.1 HP 0.1 HP 0.1 HP 0.1 HP 0.1 HP
Machine Weight 650 Kg 850 Kg 1150 Kg 1450 Kg 2200 Kg 3200 Kg 3800 Kg



Extra Accessories :

Dividing Head

Vertical Attachment

Rotary Table

Rack Cutting Attachment

Slotted Attachment

Cooling Accs

Machine Lamp

Hobbing Attachment

Machine Vice

Extra Abrour

Control Panel

Motorized feed gear box or without Rapid feed

Vertical Parking Bracket



Feeds & speeds are customized as per customer requirements also changes in . XYZ movements.
